All Terrain Crane XCA160_S
All Terrain Crane XCA160_S
XE7000 is the largest hydraulic excavator independently developed by XCMG, which meets the requirements of large-scale mining construction. It adopts dual power unit control system, equipped with intelligent monitoring and fault self diagnosis system, centralized fire extinguishing system, centralized lubrication system and various safety equipment, to ensure the safety, reliability, efficiency, simple operation and convenient maintenance of the whole machine. According to different mining construction characteristics, two power modes of diesel engine or motor, forward shovel or backhoe can be selected flexibly.
- 1,000+ vehicles per month
- After-sales service guarantee
- 7 - 40 Day
- T/T
- +86-15335315675
5-axle 160-ton all-terrain crane with excellent performance and economical operation
Seven-section “U-shaped” 75m main boom, 18.5m fixed jib, two 8m extension sections, 2.9m independent boom head, new single-cylinder pin telescopic system, 48t counterweight, five-axle H-type outrigger all-terrain chassis, four-axle drive and full-axle steering.
| Max. load capacity | 160t |
|---|---|
| Telescopic boom | 75m |
| Number of axles | 5 |
| Max. hoist height | 100.8m |
| Max.load moment | 4763kN.m |
| Drive engine model | WP12.460E50(Weichai) |
| Drive engine power | 338kw |
| Driving speed | 80km/h |
| Drive/Steering | 10×8×10 |
| Dead Weight in Travel State | 57600kg |
| Dimensions | 15785×3000×3995mm |
| Emission standard | Euro V emission standard |
